This cheat sheet is based on the AWS Certified Developer Associate walk through by Andrew Brown. Originally I wrote down the cheat sheet from his presentation. However, I thought maybe others might have a use for the same cheat sheet in a searchable format. I really encourage you to watch his walk through over at YouTube.

  • X-Ray helps developers analyze and debug applications that utilize microservice architecture
  • X-Ray is a distributed tracing system. It is a method used to profile and monitor apps especially those built using a microservice architecture, to pinpoint where failures occur and what causes poor performance
  • X-Ray Daemon is a software application that listens for traffic on UDP port 2000, gathers raw segment data and relays it to the AWS X-Ray API. Data is generally not sent directly to the X-Ray API, but passes through the X-Ray Daemon which uploads in data in bulk
  • Segments - provides the resource's name, details about the request, and details about the work done
  • Subsegments - provide more granular timing information and details about downstream calls that your app made to fulfill the original request
  • Service Graph - is a flow chart visualization of average response for microservices and to visually pinpoint failure
  • Traces - Collects all segments generated by a single request so you can track the path of requests through multiple services
  • Sampling - is an algorithm that decides which requests should be traced. By default the X-Ray SDK records the first request each second and 5% of any additional requests
  • Tracing Header - is named X-Amsn-Trace-Id and identifies a trace which are passed along to downstream services
  • Filter Expressions - allows you to narrow down specific paths or users
  • Groups - allows you to save FilterExpressions so you can quickly filter traces
  • Annotations and metadata - allow you to capture additional information in key-value pairs
  • Annotations - are indexed for use with filter expressions with a limit of 50
  • Metadata - are not indexed. Use metadata to record data you want to store in the trace but don't need to use for searching traces
  • Errors - are 400/4xx errors
  • Faults - are 400/5xx errors
  • Throttle - is 429 Too Many Requests
  • X-Ray supports the following languages: Go, Node.js, Ruby, Java, Python, ASP.NET, PHP
  • X-Ray supports AWS Service Integrations with the following: Lambda, API Gateway, App Mesh, CloudTrail, CloudWatch, AWS Config, EB, ELB, SNS, SQS, EC2, ECS Fargate
